螺杆式空气压缩机

1. 搭载康明斯或玉柴高品质品牌柴油发动机；
2. 重载发动机缸盖设计，性能卓越，能效提升；
3. 集成二合一功能，解决传统进气阀低温启动困难和活塞密封失效问题；
4. 采用弗列加空气过滤系统，双滤芯确保压缩机吸入更洁净的空气；
5. 耐高温设计，适用于严苛的高温环境；
6. 自动控制和保护系统。

Model	SMAC550-13	SMAC550-15	SMAC18-18
Screw air compressor
Layout	Screw type Single -Stage compression Oil cooling type	Screw type Single -Stage compression Oil cooling type	Screw type Single -Stage compression Oil cooling type
Free air Deliver (m³/min)	15	15	18
Discharge Pressure (bar)	13	15	18
Drive Way	Diesel Driven	Diesel Driven	Diesel Driven
Oil and Gas Tank Capacity (L)	100	100	100
Lubricating Oil Capacity（L）	48	48	48
Air Filter	FleetGuard	FleetGuard	FleetGuard
Air Compressor Head	Baosi Brand	Baosi Brand	Baosi Brand
Diesel Engine
Manufacturer	CUMMINS	CUMMINS	CUMMINS
Model	6BTA5.9-C180-II	6BTA5.9-C180-II	QSB5.9-C220-31
Rated Speed/ Full Load/ Idling (rpm)	2200/2000/1420	2200/1900/1420	2200/1950/1450
Rated Power (KW)	132	132	157
Cylinders/Cylinder Dia./ Piston Stroke	6×102×120	6×102×120	6×102×120
Output Volume (L)	5.9	5.9	5.9
Coolant Capacity (L)	20	20	20
Engine Oil Capacity (L)	17	17	17
Fuel Tank Capacity (L)	210	210	210
Air Filter	FleetGuard	FleetGuard	FleetGuard
Oil Filter	WD13145	WD13145	WD13145
Battery	6QW-165MF	6QW-165MF	6QW-165MF
Coupling	High Elastic	High Elastic	High Elastic
Walking Speed (Km/h)	0-20	0-20	0-20
Size and Weight
Length (mm)	3050 (2805 not included traction)	3050 (2805 not included traction)	3282 (2780 not included traction)
Width (mm)	1525	1525	1605
Height (mm)	2182	2182	2252
N.W (Kg)	2500	2500	2500
Exhaust Valve	G1"x1&G11/2"x1	G1"x1&G11/2"x1	G1"x1&G11/2"x1
OFFER
40HC/HQ Recommend QTY	4	4	4
1 Optional parts	none	none	none
2 Optional parts	Aftercooling	Aftercooling	none
3 Optional parts	Top Mounted Desert Air Filter	Top Mounted Desert Air Filter	Top Mounted Desert Air Filter
4 Optional parts	Diesel engine water circulation heating system	Diesel engine water circulation heating system	Diesel engine water circulation heating system
5 Optional parts	Remote Control	Remote Control	Remote Control
